Ortofon MC Windfeld Heritage cartridge

High end moving coil (MC) cartridge

Know more

Product no longer available

MPLSEOR090

+ Wishlists

  • An attentive team

  • Quality products

  • Secure and fast shipping

  • No overcharged 3x payment

Description

The Ortofon MC Windfeld Heritage cartridge is replaced by the Ortofon Windfeld Ti MC cartridge.

The MC Windfeld was developed in 2008 by Leif Johannsen and his sound engineering firm, using state-of-the-art technology. It pays tribute to an Ortofon engineer, Mr Per Windfeld, who created the most prestigious models from the past years, such as the Ortofon MC 20 Super, Concorde, MC Rohmann, MC Jubilé, Kontrapunkt, etc. The cartridge sides are adorned with the golden initials PW. It is derived from the technological contributions put forward in Ortofon's Kontrapunkt range.

The cutting-edge design of this Windfeld makes it one of the world's most elaborate models! The design builds on a central structure, made of a special alloy for optimum rigidity for an unrivalled neutrality. In addition, it includes the patented Wide Range Damping (WRD) system. Its stylus is a very high-end version of the legendary 'Replican 100' featured on the MC 3000 Mk II and MC 5000. The lightweight stylus features a very accurate and elegant polish finish. It is secured to a boron cantilever, the same one as the famous Jubilee! It is advantageously light, while being very rigid. The magnets are made of neodymium with an internal field stabilising element (FSE). The aucurum coils uses a high purity gold-plated single crystal copper conductor (99.999999% oxygen free). The coil winding method and internal coil structure produce an unprecedented channel separation and an extremely low distortion level. Allegedly, its 3 mV output level, combined with its internal impedance of 4 Ohms, make it fully compatible with all standard MC transformers and MC phono preamps.

Going straight to the point, the sound is unrivalled in terms of transparency, dynamics, details and timbre quality! The problem is finding a turntable and tonearm to match this cartridge. However, it's weight and compliance don't make this impossible. A 10" tonearm and effective weight of 8 g are required, in our opinion.

The bass is deep, very punchy and well articulated. They boast mind-blowing consistency and precision! It delivers the double bass and organ lines with unprecedented precision! The vocals and string sections are very subtle with incredibly rich harmonics! We're looking at an amazing cartridge, certainly in the top 5 or 6 on the market to date. As with all high class moving coil cartridges, the treble is precise and sharp, without any harshness and distortion. The surface noise is completely absent, allowing for true silence to step in, which is most enjoyable with classical music. The timbres are rich and very natural, making the sound very authentic. They work wonders with string and brass sections. If the Mc Anna is your dream cartridge but the price puts you off and you're nostalgic of the Jubilee, then this Ortofon MC Windfeld will do the trick nicely! An outstanding product that we can only recommend…

Franck

Type: Low output moving coil MC

Output: 0.30 mV

Load impedance: 10 Ohms

Channel separation at kHz: > 28 dB

Channel separation at 15 Hz: > 23 dB

Frequency response: 10-80 khz

Tracking ability: 100 μm

Dynamic compliance: 16 μm/mN

Stylus: Ortofon Nude Replicant

Tracking force: 2.3-2.8 g

Recommended tracking force: 2.6 g

Weight: 13 g

Coils: Gold-plated 6N copper wire

Cantilever: Ruby

Suited to medium weight tonearms

Headshell cable: OFC 8N copper (Ortofon 8N LW10).
